Objects that should be locatable in a 2D-space should inherit from this class. More...
#include <CeylanLocatable2D.h>
Public Types | |
enum | TextOutputFormat { rawText, html } |
Defines what text output formats for TextDisplayable instances are available. More... | |
enum | TextOutputFormat { rawText, html } |
Defines what text output formats for TextDisplayable instances are available. More... | |
Public Member Functions | |
Locatable2D (Locatable2D &fatherLocatable) | |
Constructs a new Locatable2D, defined relatively to its specified fatherLocatable. | |
Locatable2D () | |
Basic constructor, no local nor father referential registered. | |
Locatable2D (Locatable2D &fatherLocatable, Maths::Linear::Matrix &localReferential) | |
Constructs a new Locatable2D, defined relatively to its specified father Locatable, starting with specified local referential. | |
Locatable2D (Maths::Linear::Matrix &localReferential) | |
Basic constructor, no father referential registered, this referential is therefore considered as an absolute on. | |
virtual | ~Locatable2D () throw () |
Virtual destructor. | |
virtual Maths::Linear::Matrix & | getLocalReferential () const |
Returns this Locatable's referential, expressed in father's space. | |
virtual void | blankLocalReferential () |
Blanks local referential, so that its matrix is the identity matrix. | |
virtual Ceylan::Maths::Linear::Bipoint | getCenter () const |
Returns the center of this Locatable, expressed in father space. | |
virtual void | setCenter (const Ceylan::Maths::Linear::Bipoint &newCenter) |
Sets the center of the local referential. | |
virtual void | setCenter (Ceylan::Maths::Real newX=0, Ceylan::Maths::Real newY=0) |
Sets the center of the local referential. | |
virtual const std::string | toString (VerbosityLevels level=high) const |
Returns a user-friendly description of the state of this object. | |
virtual bool | isAbsolute () const |
Returns whether this Locatable is defined absolutely (returns true) or relatively to a father referential (returns false). | |
virtual bool | hasLocalReferential () const |
Tells whether this Locatable has a local referential available. | |
virtual void | setLocalReferential (Maths::Linear::Matrix &newGlobalReferential) |
Sets the local referential thanks to specified matrix. | |
virtual bool | hasGlobalReferential () const |
Tells whether this Locatable has a valid global referential available. | |
virtual Maths::Linear::Matrix & | getGlobalReferential () |
Returns this Locatable's referential, expressed in global (world) space. | |
virtual bool | isUpToDate () const |
Tells whether this Locatable's referential is deemed up-to-date in world (global) referential, i.e. | |
virtual void | setUpToDateState (bool newState) |
Assigns the up-to-date state of this Locatable, mostly used by father referentials to propagate a change down the referential tree. | |
virtual void | beNotifiedOf (const Event &newEvent) |
Notifies this Locatable of a new event. | |
virtual void | add (EventListener &listener) |
Registers the specified listener to this source, so that forthcoming events will be sent to it as well. | |
virtual void | remove (const EventListener &listener) |
Unregisters the specified listener from this source, no forthcoming event will be sent to the listener. | |
virtual void | removeAllListeners () |
Unsubscribes all registered listeners from this source, no forthcoming event will be sent. | |
virtual void | subscribeTo (EventSource &source) |
Subscribes this listener to the specified source, so that forthcoming events will be sent to it as well. | |
virtual void | unsubscribeFrom (EventSource &source) |
Unsubscribes this listener from specified source, no forthcoming event will be received from it. | |
virtual void | unsubscribeFromAllSources () |
Unsubscribes this listener from all registered sources, no forthcoming event will be received from any. | |
virtual void | forgetSource (EventSource &source) |
Forgets the specified source, but does not notify it that the unsubscription occured on the listener side. | |
std::list< EventSource * > | getSources () const |
Returns a shallow copy of the sources that listener is registered to. | |
Static Public Member Functions | |
static const std::string | ToString (std::list< TextDisplayable * > displayables, Ceylan::VerbosityLevels level=Ceylan::high) |
Returns a user-friendly description of this list of pointers to text displayable instances. | |
static const std::string | ToString (std::list< TextDisplayable * > displayables, Ceylan::VerbosityLevels level=Ceylan::high) |
Returns a user-friendly description of this list of pointers to text displayable instances. | |
static TextOutputFormat | GetOutputFormat () |
Returns the current overall text format to be used by TextDisplayable instances. | |
static TextOutputFormat | GetOutputFormat () |
Returns the current overall text format to be used by TextDisplayable instances. | |
static void | SetOutputFormat (TextOutputFormat newOutputFormat) |
Sets the current overall text format to be used by TextDisplayable instances. | |
static void | SetOutputFormat (TextOutputFormat newOutputFormat) |
Sets the current overall text format to be used by TextDisplayable instances. | |
Protected Member Functions | |
virtual void | updateFromFather (const Maths::Linear::Matrix &upToDateFatherReferential) |
Updates this Locatable's state (actually its precooked global referential) from specified matrix, which is the up-to-date version of this Locatable's father referential. | |
Ceylan::Maths::Linear::HomogeneousMatrix3 & | getLocalMatrix () const |
Helper non-virtual inline method to easily retrieve the internal matrix with correct (already casted) type (ex: HomogeneousMatrix3, not Matrix). | |
virtual void | changed () |
Method to be called when inner referential changed. | |
virtual void | detachFromFather () |
Detaches this Locatable from its father: their referentials will not be synchronized anymore. | |
virtual const std::string | describe (VerbosityLevels level) const |
Returns a generic description of the Locatable. | |
virtual void | notifyAllListeners (const Event &newEvent) |
Notifies all currently registered listeners of a new event. | |
virtual bool | isRegistered (const EventListener &listener) |
Tells whether specified listener is registered to this source. | |
Protected Attributes | |
Locatable * | _father |
This referential's father, if any. | |
Maths::Linear::Matrix * | _localReferential |
The internal referential corresponding to this Locatable, expressed in father's space. | |
Maths::Linear::Matrix * | _globalReferential |
Pre-computed referential, from world space (global) to this referential. | |
ReferentialChangedEvent * | _changedEvent |
This internal event is allocated the first time this Locatable changes its referential, one time for all: for next changes, that same event will be changed accordingly abd then propagated again. | |
std::list< EventListener * > | _listeners |
The registered event listeners. | |
std::list< EventSource * > | _sources |
The event sources to which this listener is subscribed to. | |
Static Protected Attributes | |
static TextOutputFormat | _OutputFormat = rawText |
The text format to be used currently by TextDisplayable instances. | |
static TextOutputFormat | _OutputFormat = rawText |
The text format to be used currently by TextDisplayable instances. |
Objects that should be locatable in a 2D-space should inherit from this class.
A referential is defined by both a point in space and a set of angles or vectors that indicates which orientation it has.
Definition at line 56 of file CeylanLocatable2D.h.
enum Ceylan::TextDisplayable::TextOutputFormat [inherited] |
Defines what text output formats for TextDisplayable instances are available.
Definition at line 124 of file CeylanTextDisplayable.h.
enum Ceylan::TextDisplayable::TextOutputFormat [inherited] |
Defines what text output formats for TextDisplayable instances are available.
Definition at line 124 of file CeylanTextDisplayable.h.
Locatable2D::Locatable2D | ( | Locatable2D & | fatherLocatable | ) | [explicit] |
Constructs a new Locatable2D, defined relatively to its specified fatherLocatable.
This local referential describes on creation the same referential as the father one, since the transformation between this referential and its fathers is the identity.
Definition at line 54 of file CeylanLocatable2D.cc.
References blankLocalReferential().
Locatable2D::Locatable2D | ( | ) |
Basic constructor, no local nor father referential registered.
Definition at line 64 of file CeylanLocatable2D.cc.
References blankLocalReferential().
Locatable2D::Locatable2D | ( | Locatable2D & | fatherLocatable, | |
Maths::Linear::Matrix & | localReferential | |||
) |
Constructs a new Locatable2D, defined relatively to its specified father Locatable, starting with specified local referential.
fatherLocatable | the referential this referential is relative to. | |
localReferential | the transformation from this local referential to its father referential. |
Definition at line 74 of file CeylanLocatable2D.cc.
Locatable2D::Locatable2D | ( | Maths::Linear::Matrix & | localReferential | ) | [explicit] |
Basic constructor, no father referential registered, this referential is therefore considered as an absolute on.
Its local referential, which is in this particular case a global one too, is specified.
Definition at line 83 of file CeylanLocatable2D.cc.
Locatable2D::~Locatable2D | ( | ) | throw () [virtual] |
Virtual destructor.
Definition at line 91 of file CeylanLocatable2D.cc.
void EventSource::add | ( | EventListener & | listener | ) | [virtual, inherited] |
Registers the specified listener to this source, so that forthcoming events will be sent to it as well.
EventException | if listener is already registered to the event source. |
Definition at line 118 of file CeylanEventSource.cc.
References Ceylan::EventSource::_listeners, and Ceylan::EventListener::toString().
Referenced by Ceylan::Model::addView(), Ceylan::EventSource::EventSource(), and Ceylan::EventListener::subscribeTo().
void Locatable::beNotifiedOf | ( | const Event & | newEvent | ) | [virtual, inherited] |
Notifies this Locatable of a new event.
Implements Ceylan::EventListener.
Definition at line 361 of file CeylanLocatable.cc.
References Ceylan::Locatable::setUpToDateState().
void Locatable2D::blankLocalReferential | ( | ) | [virtual] |
Blanks local referential, so that its matrix is the identity matrix.
Implements Ceylan::Locatable.
Definition at line 120 of file CeylanLocatable2D.cc.
References Ceylan::Locatable::_localReferential, and Ceylan::Maths::Linear::Matrix::setToIdentity().
Referenced by Locatable2D().
void Locatable::changed | ( | ) | [protected, virtual, inherited] |
Method to be called when inner referential changed.
Its role is to propagate a corresponding ReferentialChangedEvent to this Locatable's children.
Definition at line 389 of file CeylanLocatable.cc.
References Ceylan::Locatable::_changedEvent, Ceylan::Locatable::_globalReferential, and Ceylan::EventSource::notifyAllListeners().
Referenced by Ceylan::Locatable::setUpToDateState().
const string Locatable::describe | ( | VerbosityLevels | level | ) | const [protected, virtual, inherited] |
Returns a generic description of the Locatable.
Useful to share this part of the description among the children to ease toString management.
Definition at line 430 of file CeylanLocatable.cc.
References Ceylan::Locatable::_globalReferential, Ceylan::EventSource::_listeners, Ceylan::Locatable::_localReferential, Ceylan::high, Ceylan::Locatable::toString(), and Ceylan::Maths::Linear::Matrix::toString().
Referenced by toString(), and Ceylan::Locatable::toString().
void Locatable::detachFromFather | ( | ) | [protected, virtual, inherited] |
Detaches this Locatable from its father: their referentials will not be synchronized anymore.
LocatableException | if this Locatable had no father or was not linked to it. |
Definition at line 408 of file CeylanLocatable.cc.
References Ceylan::Locatable::_father, dataUtils::e, Ceylan::Exception::toString(), and Ceylan::EventListener::unsubscribeFrom().
Referenced by Ceylan::Locatable::~Locatable().
void EventListener::forgetSource | ( | EventSource & | source | ) | [virtual, inherited] |
Forgets the specified source, but does not notify it that the unsubscription occured on the listener side.
Therefore, if the source were to send new events, this listener would be notified, and may not be aware it received an event from a source it is not registered to any more.
This method should mostly be used by event sources being deallocated, having realized that some listeners were still subscribed, and wanting nevertheless that the listeners remove these sources from their list. Otherwise, on the source side, should unsubscribeFrom be used instead, the listeners list would be modified in turn while iterating on it in the source destructor, which may cause a crash.
Alternatively, on these listener deallocations, if nothing was done in the case of a deallocated source still having at least one listener left, a call to the remove method of these source instances would be tempted, and may cause a crash since sources could be already deallocated.
This listener can be registered multiple times to this source.
EventException | if listener was not already registered to the event source, and if debug mode for events is activated. |
Definition at line 191 of file CeylanEventListener.cc.
References Ceylan::EventListener::_sources, generalUtils::false, Ceylan::EventSource::toString(), and generalUtils::true.
Bipoint Locatable2D::getCenter | ( | ) | const [virtual] |
Returns the center of this Locatable, expressed in father space.
Coordinates are modified according to the homogeneous factor: they are normalized.
LocatableException | if no relevant local referential was available, or if the homogeneous factor is zero. |
Definition at line 133 of file CeylanLocatable2D.cc.
References Ceylan::Maths::Linear::Matrix3::getElementAt(), getLocalMatrix(), Ceylan::Maths::IsNull(), and Ceylan::toString().
Matrix & Locatable::getGlobalReferential | ( | ) | [virtual, inherited] |
Returns this Locatable's referential, expressed in global (world) space.
LocatableException | if no referential is available. |
Definition at line 262 of file CeylanLocatable.cc.
References Ceylan::Locatable::_father, Ceylan::Locatable::_globalReferential, Ceylan::Locatable::_isUpToDate, Ceylan::Locatable::_localReferential, Ceylan::emergencyShutdown(), Ceylan::Locatable::getGlobalReferential(), Ceylan::Locatable::isAbsolute(), Ceylan::Locatable::setUpToDateState(), and Ceylan::Locatable::updateFromFather().
Referenced by Ceylan::Locatable::getGlobalReferential().
Ceylan::Maths::Linear::HomogeneousMatrix3& Ceylan::Locatable2D::getLocalMatrix | ( | ) | const [inline, protected] |
Helper non-virtual inline method to easily retrieve the internal matrix with correct (already casted) type (ex: HomogeneousMatrix3, not Matrix).
Definition at line 255 of file CeylanLocatable2D.h.
References generalUtils::temp.
Referenced by getCenter(), and setCenter().
Matrix & Locatable2D::getLocalReferential | ( | ) | const [virtual] |
Returns this Locatable's referential, expressed in father's space.
Reimplemented from Ceylan::Locatable.
Definition at line 100 of file CeylanLocatable2D.cc.
References Ceylan::Locatable::_localReferential.
TextDisplayable::TextOutputFormat TextDisplayable::GetOutputFormat | ( | ) | [static, inherited] |
Returns the current overall text format to be used by TextDisplayable instances.
Definition at line 63 of file CeylanTextDisplayable.cc.
References Ceylan::TextDisplayable::_OutputFormat.
Referenced by Ceylan::formatStringList(), Ceylan::formatStringMap(), Ceylan::XML::XMLMarkup::toString(), Ceylan::Maths::Linear::Vector3::toString(), Ceylan::Maths::Linear::Vector2::toString(), Ceylan::Maths::Linear::Tripoint::toString(), Ceylan::Module::toString(), Ceylan::Maths::Linear::Matrix3::toString(), Ceylan::Maths::Linear::Matrix2::toString(), Ceylan::Maths::Linear::HomogeneousMatrix3::toString(), and Ceylan::Maths::Linear::Bipoint::toString().
TextDisplayable::TextOutputFormat TextDisplayable::GetOutputFormat | ( | ) | [static, inherited] |
Returns the current overall text format to be used by TextDisplayable instances.
Definition at line 63 of file CeylanTextDisplayable.cc.
References Ceylan::TextDisplayable::_OutputFormat.
Referenced by Ceylan::formatStringList(), Ceylan::formatStringMap(), Ceylan::XML::XMLMarkup::toString(), Ceylan::Maths::Linear::Vector3::toString(), Ceylan::Maths::Linear::Vector2::toString(), Ceylan::Maths::Linear::Tripoint::toString(), Ceylan::Module::toString(), Ceylan::Maths::Linear::Matrix3::toString(), Ceylan::Maths::Linear::Matrix2::toString(), Ceylan::Maths::Linear::HomogeneousMatrix3::toString(), and Ceylan::Maths::Linear::Bipoint::toString().
list< EventSource * > EventListener::getSources | ( | ) | const [inherited] |
Returns a shallow copy of the sources that listener is registered to.
Definition at line 238 of file CeylanEventListener.cc.
References Ceylan::EventListener::_sources.
bool Locatable::hasGlobalReferential | ( | ) | const [virtual, inherited] |
Tells whether this Locatable has a valid global referential available.
Definition at line 253 of file CeylanLocatable.cc.
References Ceylan::Locatable::_globalReferential.
bool Locatable::hasLocalReferential | ( | ) | const [virtual, inherited] |
Tells whether this Locatable has a local referential available.
Definition at line 222 of file CeylanLocatable.cc.
References Ceylan::Locatable::_localReferential.
bool Locatable::isAbsolute | ( | ) | const [virtual, inherited] |
Returns whether this Locatable is defined absolutely (returns true) or relatively to a father referential (returns false).
Definition at line 213 of file CeylanLocatable.cc.
References Ceylan::Locatable::_father.
Referenced by Ceylan::Locatable::getGlobalReferential(), toString(), and Ceylan::Locatable::toString().
bool EventSource::isRegistered | ( | const EventListener & | listener | ) | [protected, virtual, inherited] |
Tells whether specified listener is registered to this source.
Definition at line 252 of file CeylanEventSource.cc.
References Ceylan::EventSource::_listeners, and generalUtils::false.
bool Locatable::isUpToDate | ( | ) | const [virtual, inherited] |
Tells whether this Locatable's referential is deemed up-to-date in world (global) referential, i.e.
if all the Locatable instances from this one to the root of its tree are up-to-date, bounds included.
Definition at line 324 of file CeylanLocatable.cc.
References Ceylan::Locatable::_isUpToDate.
void EventSource::notifyAllListeners | ( | const Event & | newEvent | ) | [protected, virtual, inherited] |
Notifies all currently registered listeners of a new event.
Definition at line 270 of file CeylanEventSource.cc.
References Ceylan::EventSource::_listeners.
Referenced by Ceylan::Locatable::changed(), and Ceylan::Model::notifyAllViews().
void EventSource::remove | ( | const EventListener & | listener | ) | [virtual, inherited] |
Unregisters the specified listener from this source, no forthcoming event will be sent to the listener.
EventException | if listener was not already registered to the event source. |
Definition at line 142 of file CeylanEventSource.cc.
References Ceylan::EventSource::_listeners, generalUtils::false, Ceylan::EventListener::toString(), and generalUtils::true.
void EventSource::removeAllListeners | ( | ) | [virtual, inherited] |
Unsubscribes all registered listeners from this source, no forthcoming event will be sent.
This source will request each of its listeners to unsubscribe from it, then the source will forget them in turn.
The links will be removed, but no instance will be deleted by this call.
Definition at line 204 of file CeylanEventSource.cc.
References Ceylan::EventSource::_listeners.
Referenced by Ceylan::Model::removeAllViews(), and Ceylan::Locatable::~Locatable().
virtual void Ceylan::Locatable2D::setCenter | ( | Ceylan::Maths::Real | newX = 0 , |
|
Ceylan::Maths::Real | newY = 0 | |||
) | [virtual] |
Sets the center of the local referential.
As it is relative to father locatable, it must be defined in father space.
newX | the new center abscissa, in father space. | |
newX | the new center ordinate, in father space. |
LocatableException | if no local referential was available. |
void Locatable2D::setCenter | ( | const Ceylan::Maths::Linear::Bipoint & | newCenter | ) | [virtual] |
Sets the center of the local referential.
As it is relative to father locatable, it must be defined in father space.
newCenter | the new center, in father space. |
LocatableException | if no local referential was available. |
Definition at line 153 of file CeylanLocatable2D.cc.
References Ceylan::Locatable::_localReferential, getLocalMatrix(), Ceylan::Maths::Linear::Bipoint::getX(), Ceylan::Maths::Linear::Bipoint::getY(), Ceylan::Maths::Linear::Matrix3::setElementAt(), and Ceylan::Locatable::setUpToDateState().
void Locatable::setLocalReferential | ( | Maths::Linear::Matrix & | newGlobalReferential | ) | [virtual, inherited] |
Sets the local referential thanks to specified matrix.
Definition at line 244 of file CeylanLocatable.cc.
References Ceylan::Locatable::_localReferential.
void TextDisplayable::SetOutputFormat | ( | TextOutputFormat | newOutputFormat | ) | [static, inherited] |
Sets the current overall text format to be used by TextDisplayable instances.
newOutputFormat | the new output format. |
Definition at line 72 of file CeylanTextDisplayable.cc.
References Ceylan::TextDisplayable::_OutputFormat.
Referenced by Ceylan::Log::LogHolder::LogHolder().
void TextDisplayable::SetOutputFormat | ( | TextOutputFormat | newOutputFormat | ) | [static, inherited] |
Sets the current overall text format to be used by TextDisplayable instances.
newOutputFormat | the new output format. |
Definition at line 72 of file CeylanTextDisplayable.cc.
References Ceylan::TextDisplayable::_OutputFormat.
Referenced by Ceylan::Log::LogHolder::LogHolder().
void Locatable::setUpToDateState | ( | bool | newState | ) | [virtual, inherited] |
Assigns the up-to-date state of this Locatable, mostly used by father referentials to propagate a change down the referential tree.
Definition at line 333 of file CeylanLocatable.cc.
References Ceylan::Locatable::_isUpToDate, and Ceylan::Locatable::changed().
Referenced by Ceylan::Locatable::beNotifiedOf(), Ceylan::Locatable::getGlobalReferential(), and setCenter().
void EventListener::subscribeTo | ( | EventSource & | source | ) | [virtual, inherited] |
Subscribes this listener to the specified source, so that forthcoming events will be sent to it as well.
EventException | if listener is already registered to the specified event source. |
Definition at line 87 of file CeylanEventListener.cc.
References Ceylan::EventListener::_sources, Ceylan::EventSource::add(), and Ceylan::EventSource::toString().
Referenced by Ceylan::Controller::Controller(), Ceylan::EventListener::EventListener(), Ceylan::Locatable::Locatable(), and Ceylan::Model::subscribeToController().
const std::string TextDisplayable::ToString | ( | std::list< TextDisplayable * > | displayables, | |
Ceylan::VerbosityLevels | level = Ceylan::high | |||
) | [static, inherited] |
Returns a user-friendly description of this list of pointers to text displayable instances.
displayables | a list of pointers to TextDisplayable instances/ | |
level | the requested verbosity level. |
Definition at line 45 of file CeylanTextDisplayable.cc.
References Ceylan::formatStringList().
const std::string TextDisplayable::ToString | ( | std::list< TextDisplayable * > | displayables, | |
Ceylan::VerbosityLevels | level = Ceylan::high | |||
) | [static, inherited] |
Returns a user-friendly description of this list of pointers to text displayable instances.
displayables | a list of pointers to TextDisplayable instances/ | |
level | the requested verbosity level. |
Definition at line 45 of file CeylanTextDisplayable.cc.
References Ceylan::formatStringList().
const string Locatable2D::toString | ( | VerbosityLevels | level = high |
) | const [virtual] |
Returns a user-friendly description of the state of this object.
level | the requested verbosity level. |
Reimplemented from Ceylan::Locatable.
Definition at line 200 of file CeylanLocatable2D.cc.
References Ceylan::Locatable::describe(), and Ceylan::Locatable::isAbsolute().
void EventListener::unsubscribeFrom | ( | EventSource & | source | ) | [virtual, inherited] |
Unsubscribes this listener from specified source, no forthcoming event will be received from it.
This is the usual method to call when one wants that this listener to not listen any more to the specified source.
It is in fact implemented by notifying this source of the unsubscription of this listener, and by forgetting it.
EventException | if listener was not already registered to the event source. |
Definition at line 113 of file CeylanEventListener.cc.
References Ceylan::EventListener::_sources, and Ceylan::EventSource::toString().
Referenced by Ceylan::Locatable::detachFromFather(), and Ceylan::Model::unsubscribeFromController().
void EventListener::unsubscribeFromAllSources | ( | ) | [virtual, inherited] |
Unsubscribes this listener from all registered sources, no forthcoming event will be received from any.
Definition at line 160 of file CeylanEventListener.cc.
References Ceylan::EventListener::_sources.
Referenced by Ceylan::Model::unsubscribeFromAllControllers(), and Ceylan::EventListener::~EventListener().
void Locatable2D::updateFromFather | ( | const Maths::Linear::Matrix & | upToDateFatherReferential | ) | [protected, virtual] |
Updates this Locatable's state (actually its precooked global referential) from specified matrix, which is the up-to-date version of this Locatable's father referential.
Implements Ceylan::Locatable.
Definition at line 217 of file CeylanLocatable2D.cc.
References Ceylan::Locatable::_globalReferential, Ceylan::Locatable::_localReferential, Ceylan::emergencyShutdown(), and dataUtils::m.
ReferentialChangedEvent* Ceylan::Locatable::_changedEvent [protected, inherited] |
This internal event is allocated the first time this Locatable changes its referential, one time for all: for next changes, that same event will be changed accordingly abd then propagated again.
Definition at line 502 of file CeylanLocatable.h.
Referenced by Ceylan::Locatable::changed(), and Ceylan::Locatable::~Locatable().
Locatable* Ceylan::Locatable::_father [protected, inherited] |
This referential's father, if any.
Definition at line 468 of file CeylanLocatable.h.
Referenced by Ceylan::Locatable::detachFromFather(), Ceylan::Locatable::getGlobalReferential(), Ceylan::Locatable::isAbsolute(), Ceylan::Locatable::Locatable(), and Ceylan::Locatable::~Locatable().
Maths::Linear::Matrix* Ceylan::Locatable::_globalReferential [protected, inherited] |
Pre-computed referential, from world space (global) to this referential.
Definition at line 490 of file CeylanLocatable.h.
Referenced by Ceylan::Locatable::changed(), Ceylan::Locatable::describe(), Ceylan::Locatable::getGlobalReferential(), Ceylan::Locatable::hasGlobalReferential(), updateFromFather(), and Ceylan::Locatable::~Locatable().
std::list<EventListener *> Ceylan::EventSource::_listeners [protected, inherited] |
The registered event listeners.
Definition at line 204 of file CeylanEventSource.h.
Referenced by Ceylan::EventSource::add(), Ceylan::Locatable::describe(), Ceylan::EventSource::isRegistered(), Ceylan::EventSource::notifyAllListeners(), Ceylan::EventSource::remove(), Ceylan::EventSource::removeAllListeners(), Ceylan::Model::toString(), Ceylan::EventSource::toString(), Ceylan::Controller::toString(), and Ceylan::EventSource::~EventSource().
Maths::Linear::Matrix* Ceylan::Locatable::_localReferential [protected, inherited] |
The internal referential corresponding to this Locatable, expressed in father's space.
Definition at line 479 of file CeylanLocatable.h.
Referenced by blankLocalReferential(), Ceylan::Locatable::describe(), Ceylan::Locatable::getGlobalReferential(), getLocalReferential(), Ceylan::Locatable::getLocalReferential(), Ceylan::Locatable::hasLocalReferential(), setCenter(), Ceylan::Locatable::setLocalReferential(), updateFromFather(), and Ceylan::Locatable::~Locatable().
TextDisplayable::TextOutputFormat TextDisplayable::_OutputFormat = rawText [static, protected, inherited] |
The text format to be used currently by TextDisplayable instances.
Definition at line 158 of file CeylanTextDisplayable.h.
Referenced by Ceylan::TextDisplayable::GetOutputFormat(), and Ceylan::TextDisplayable::SetOutputFormat().
TextDisplayable::TextOutputFormat TextDisplayable::_OutputFormat = rawText [static, protected, inherited] |
The text format to be used currently by TextDisplayable instances.
Definition at line 158 of file CeylanTextDisplayable.h.
Referenced by Ceylan::TextDisplayable::GetOutputFormat(), and Ceylan::TextDisplayable::SetOutputFormat().
std::list<EventSource *> Ceylan::EventListener::_sources [protected, inherited] |
The event sources to which this listener is subscribed to.
Definition at line 233 of file CeylanEventListener.h.
Referenced by Ceylan::EventListener::forgetSource(), Ceylan::View::getModel(), Ceylan::EventListener::getSources(), Ceylan::EventListener::subscribeTo(), Ceylan::View::toString(), Ceylan::Model::toString(), Ceylan::EventListener::toString(), Ceylan::EventListener::unsubscribeFrom(), Ceylan::EventListener::unsubscribeFromAllSources(), and Ceylan::EventListener::~EventListener().
